• Resolution: 1920×1080/1280×720
• Frame Rate: 60 fps @ 1080p/60 fps @ 720p
• Shutter Speed: 1/30, 1/50 (50Hz), 1/60, 1/100 (50Hz), 1/120 second
• Format: 16:9
• Illumination: 150 lux to daylight
• Exposure: Auto/EV adjustment
• White Balance: Auto/manual
• Focus: Auto, passive contrast
• Focus Range: 30 cm (12”) to infinite

Lens and Image Sensor

• Lens Construction: 12 element zoom
• Aperture: F/2.8—F/4.2
• Distortion: Less than 5%
• Sensor Type: CMOS
• Effective Pixels: 2,073,600
• SNR: 52 dB

Pan/Tilt/Zoom

• Pan Angle: +/– 87.5° (245° total view range)
• Tilt Angle: +/– 30° (102° total view range)
• Optical Zoom: 10x
• Diagonal field of view: 81 degrees
• Horizontal field of view: 73 degrees
• Vertical field of view: 44 degrees
• Aperture Priority: Fixed

Features

• Tripod Mount: Standard ¼-20 tripod mount
• Self Check-up: Yes
• Presets: 10

Interface

• 1 x HD Camera Port (1080p/720p)

Cables

• 1 x HDMI (3M/ 9.8 ft)

Power Supply

• Universal input AC/DC provided
• 100-240VAC 50/60HZ
• 20w typical, 46w maximum

Lens Cap

• Included

Antiglare Visor

• Included

Cable Lengths

• Additional distances possible with third-party HDMI extenders
• Tested: Extron HDMI 201, 170 feet (52 meters)

Overall Dimensions

• Width: 184 mm (7.25”)
• Depth: 148 mm (5.83”)
• Height: 156 mm (6.14”)
• Weight (with shroud): 1.4 kg (2.998 lbs)
• Shipping Weight: 2.6 kg (5.7 lbs)

Environmental Parameters

• Operating Temperature: 0°C (32°F) to 40°C (104°F)
• Operating Humidity: 15% to 85%, noncondensing
• Storage Temperature: –20°C (–4°F) to 60°C (140°F)
• Storage Humidity: 10% to 90%, noncondensing
